Hyundai i20N Wheel Fitment Guide

I have included dimensions from Will They Fit down below.
Factory wheel fitment isn't terrible but it's only not terrible because the factory guards don't allow for a very large tyre 🙁. Coilovers will give you some room on the front but the rear you will almost always be limited to a 225 wide tyre at the most +45

Factory Wheels
PCD: 5x114.3
Offset: ET53
Hub/Centre Bore: 67.1mm
Torque Specs: 107-127nm
Wheel Weight: 12.1kg
Factory Tyre: Pirelli P-Zero HN 215/40R18

Recommended Tyre Pressures:
Road: F/R: 32Psi
Track: 32Psi Front 29Psi Rear (Recommended hot pressures)

Common Tyre Size Change:
Factory Wheels: 225/40R18 - Provides a bit better ride comfort. Have seen one person report scrub otherwise no reported issues.

Safe setups:

Wheel:
17x7.5 +45
17x8 + 50
18x7.5+45
18x8 +50

Tyre:
17s: 215/45R17 or 225/45R17
18s: 215/40R18 or 225/40R18

Aggressive Setups. (expect some scrub)

Wheels
17x8 or 8.5 +45
18x8 or 8.5 +45
Tyres:
17s:
Front: 235/45r17 or 225/45r17
Rear: 225/45R17
18s
Front: 235/40r18 or 225/40r18
Rear: 225/40R18
